Enhanced surfacing
Auto Surface with selective surfacing, Surface Offset, Fill Face, and extend, trim, untrim and sew for surface bodies.
Plus adds the tools that make moderately complex parts faster to model, and connects Design X directly to portable arms, laser trackers and structured light scanners.
Geomagic Design X Plus 2026
Geomagic® Design X™ is Hexagon’s reverse engineering software. It combines 3D scan processing with history-based CAD modeling, so you can turn a physical part into a feature-based, editable model that works with your other design software.
Design X Plus is the middle plan. Hexagon describes it as an enhanced toolset that integrates directly with your scanner to help you create usable CAD, faster. It includes everything in Go, then adds solid offset and shell, selective Auto Surface, surface trimming and sewing, draft and patterns, the full Accuracy Analyzer, and direct control of portable arms, laser trackers and structured light scanners with probing.
It suits professionals doing regular, moderately complex reverse engineering who do not need native CAD import or the modeling wizards in Pro. The current release is Geomagic Design X 2026.1.0.
What Plus adds
Plus keeps the full Go workflow and adds the tools that save time on parts with more surfaces, more features and more measured data.
Auto Surface with selective surfacing, Surface Offset, Fill Face, and extend, trim, untrim and sew for surface bodies.
Solid Offset, Shell and Thicken Surface, plus Draft, linear and circular patterns, Mirror, Transform Body and Delete Face.
Direct control of Hexagon Absolute Arm, Romer, Leica T-Probe, T-Scan and AT960, FARO Cobalt, Aicon and Hexagon structured light scanners.
LiveAlign, LiveCapture, LiveModel and LiveGeometry, with probe location, move device and device connection tools.
Edit Boundaries, Defeature, Trim, Convert To Mesh and Shrink Wrap, 3D mesh sketches, tangent and coincident constraint settings, and 3D sketch editing.
Hexagon’s real-time Accuracy Analyzer for checking the model against the scan, plus faster vendor support: phone, remote session and workflow help.
Device integration
With Plus, scanning and probing happen in Design X itself, so you do not have to export, convert and re-import data between programs.
CAD interoperability
Every Design X plan includes LiveTransfer, which sends the finished model into your CAD system with the feature tree intact.
New to the workflow? Read the complete guide to scan-to-CAD.
2026.1.0
The 2026.1.0 release, from March 2026, adds device support and improves tools Plus users rely on.
How it works
Scan or probe directly in Design X with a supported scanner, arm or tracker, or import data from any scanner.
Heal the mesh, edit boundaries, defeature and fill holes, then define regions and align the data.
Build solids and surfaces with selective Auto Surface, offsets, shells, trims, drafts and patterns.
Check the model against the scan with the Accuracy Analyzer, then LiveTransfer it to CAD.
Go, Plus or Pro
Plus includes everything in Go. This is where it sits between the entry plan and the complete Pro plan.
| Feature | Go | Plus | Pro |
|---|---|---|---|
| Neutral file import and export Point data (PTS), meshes (STL), scanner formats, STEP, IGES, DXF | Included | Included | Included |
| LiveTransfer to CAD SOLIDWORKS, NX, Creo, AutoCAD, Inventor | Included | Included | Included |
| Native CAD and Parasolid import ACIS, CATIA, Creo, NX, SolidWorks, Inventor, VDA-FS, Rhino, JT, Solid Edge | Not included | Not included | Included |
| Parasolid, Leica, KeyShot and native CAD export Native export: ACIS, CATIA | Not included | Not included | Included |
| Core solid modeling Extrude, Revolve, Sweep, Loft, Cut, Boolean, Fillet, Chamfer, primitives | Included | Included | Included |
| Solid Offset, Shell, Thicken Surface | Not included | Included | Included |
| Draft, patterns, Mirror, Transform Body, Delete Face | Not included | Included | Included |
| Mesh Fit and Auto Surface Without selective surfacing | Included | Included | Included |
| Selective Auto Surface, Surface Offset, Fill Face, Trim and Sew | Not included | Included | Included |
| Fit Surface Patches, Boundary Fit, Solidify | Not included | Not included | Included |
| Modeling wizards Extrusion, Revolution, Sweep, Loft and Pipe wizards | Not included | Not included | Included |
| Scanner direct control: handheld and portable scanners Hexagon/ZG handheld, Creaform, Konica Minolta Range, Shining 3D, eviXscan, Scantech DefinSight and Tviewer | Included | Included | Included |
| Scanner direct control: arms, trackers and structured light Hexagon Absolute Arm, Romer, FARO Cobalt, Leica T-Probe, T-Scan and AT960, Aicon and more | Not included | Included | Included |
| Probing LiveAlign, LiveCapture, LiveModel, LiveGeometry | Not included | Included | Included |
| Core mesh tools Healing Wizard, Fix Normal, Global Remesh, Fill Holes, Smooth, Split, Offset | Included | Included | Included |
| Edit Boundaries, Defeature, Trim, Shrink Wrap | Not included | Included | Included |
| Advanced mesh and point cloud tools Rewrap, Virtual Rescan, Optimize Mesh, Smart Brush, Construct Mesh, Auto Segment | Not included | Not included | Included |
| Texture tools and batch scan processing Process Designer, Run Scan Process, Batch Process | Not included | Not included | Included |
| Interactive Alignment | Included | Included | Included |
| Quick Fit, Best Fit, Datum Match, Align Wizard Plus target and sphere registration | Not included | Not included | Included |
| Accuracy Analyzer Body, mesh and sketch deviation in every plan; full analyzer in Plus and Pro | Deviation | Included | Included |
| AutoSketch, Find Defect, Refit and add-ins | Not included | Not included | Included |
| Vendor support Email, installation and licensing support, Knowledge Base access | Included | Included | Included |
| Phone, remote session and workflow support Case response in 1 business day (Go: 3 business days) | Not included | Included | Included |
Summary of Hexagon’s 2026 Geomagic Design X plan comparison. Download the full comparison below, or compare the Go, Plus and Pro pages. Not sure which plan fits? Tell us about your parts and scanner and we will recommend one.
Compatibility
Plus works with scan data from any scanner, controls handheld scanners directly, and adds direct control of arms, trackers and structured light scanners.
Using a scanner from us? Scantech’s DefinSight and Tviewer software are on the direct-control list in every Design X plan, which covers SCANOLOGY (Scantech) scanners. Scans from Artec scanners come in as standard mesh or point cloud files exported from Artec Studio, and Design X works with data from any scanner this way.
Technical specifications
Requirements for Geomagic Design X 2026.1.0, as published by Hexagon. They are the same for Go, Plus and Pro. Large scans are demanding, so plan around the recommended configuration.
Hexagon's minimum supported configuration.
For large meshes and point clouds.
Buying a workstation for scanning? Ask us before you order and we will check the spec.
Why buy from us
We sell, set up and support 3D scanners and reverse engineering software together, so you have one team to call for the whole scan-to-CAD workflow.
Training, technical support and updates are included with all software we sell.
We can arrange a free trial of Geomagic Design X Plus so you can test it on your own scans before you buy.
Pair Design X with a scanner we sell and set up, and keep one point of contact.
Not ready to buy? Our reverse engineering service turns your parts into CAD for you.
Request a free trial, or tell us about your parts, your scanner and the CAD system you use and we will confirm the right Geomagic Design X plan.
Already a Geomagic Design X user? Contact us about renewing your license.
Plus is the middle plan of Geomagic Design X, Hexagon’s reverse engineering software. It includes everything in Go and adds an enhanced modeling toolset, the full Accuracy Analyzer, and direct integration with scanners, portable arms and laser trackers.
Professionals who do regular, moderately complex reverse engineering and want to scan or probe directly in Design X, but who do not need native CAD import or the modeling wizards in Pro.
Solid Offset, Shell and Thicken Surface; selective Auto Surface, Surface Offset, Fill Face, trim and sew; Draft, patterns and Mirror; Edit Boundaries, Defeature and Shrink Wrap; 3D mesh sketches; direct control of arms, trackers and structured light scanners; probing with LiveAlign and LiveCapture; the full Accuracy Analyzer; and phone, remote session and workflow support from Hexagon.
Native CAD and Parasolid import, Parasolid and native CAD export, the Extrusion, Revolution, Sweep, Loft and Pipe modeling wizards, Fit Surface Patches, Boundary Fit and Solidify, advanced mesh and point cloud tools such as Rewrap and Virtual Rescan, Auto Segment, texture tools, batch scan processing, AutoSketch and the Best Fit and Align Wizard alignments. See Geomagic Design X Pro.
Handheld and portable scanners from Hexagon/ZG, Creaform, Konica Minolta (Range5 and Range7), Shining 3D, eviXscan and Scantech (DefinSight and Tviewer), plus Hexagon Absolute Arm, Romer Infinite and Stinger, Hexagon structured light scanners, FARO Cobalt Array Imager, Aicon, Leica T-Probe, T-Scan TS50 and Absolute Tracker AT960, and Konica Minolta VIVID.
No. Plus imports and exports neutral CAD formats such as STEP and IGES, plus DXF, and sends models to CAD with LiveTransfer. Native CAD and Parasolid import is in Geomagic Design X Pro.
Version 2026.1.0, released in March 2026, adds a ZG handheld scanner plug-in, Scantech DefinSight support, RDS 6.6 hardware support, a more flexible Split Mesh tool, faster Fill Holes, LiveTransfer support for SOLIDWORKS 2026 and an updated licensing system.
Hexagon. Hexagon completed its acquisition of the Geomagic software suite from 3D Systems in April 2025, and Geomagic Design X is now developed and supported within Hexagon’s Manufacturing Intelligence division. Older material may still show the 3D Systems or Oqton names.
Pricing is quoted. It depends on the plan (Go, Plus or Pro), the options you need and the license type. Contact us for a quote or request a free trial.
A 64-bit Windows 10 or later PC. Hexagon’s minimum for version 2026.1.0 is an Intel or AMD 64-bit processor, 8 GB of RAM, 30 GB of free disk space and an NVIDIA GPU with OpenGL 4.0 and 2 GB of VRAM. Hexagon recommends Windows 11, a recent Core i7/i9 or Ryzen 7/9, 32 GB of RAM or more, an SSD and an NVIDIA RTX card with 4 GB of VRAM or more. The requirements are the same for every plan.
Yes. Training, technical support and updates are included with all software we sell. From Hexagon, Plus adds phone, remote session and usage and workflow support, with case response in one business day.
